Survey Construction & Procedures
Date: 1st, 2nd & 3rd March 2021
Time: 1pm to 4:15pm (AEDT - SYDNEY TIME) w/ 15-minute break
Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.
An Internet Connection is required.
12d Model v15 and Codemeter drivers : 12d Model v15 Installation Document
Civil and Surveying Institute will supply a 12d Model licence and data to use for the course
Course Places: 4 seats available
14.0 SURVEY CONSTRUCTION PROCEDURES Course ID: 2DSCP
Prerequisites: Experience in 12d Model with completion of the One Day Survey Basics course or working through the ‘Getting Started for Surveying’ Manual is required.
Course Content: This course is only for experienced 12d Model surveyors.
• Importing Road design
• 12d Archive
• Genio
• DWG
• Analysis and checking
• String conversions and filtering
• Cross section creation
• Boxing creation
• Point cloud
• Import
• Thinning
• Tinning
• Volumes
• Stockpile volumes
• Progressive volumes
• Isopachs and shading
• Setout
• Road
• Structure cad entry
• Uploading points / string
• Road upload
• Machine control upload
• Plotting
• House setout
• Road Construction
• Index & layout plans
• Long & Cross sections
• Volume reports
• Plot book Important
